Tycon Power Systems TP-VRHP-2424 70W 18-36VDC to 24VDC Voltage Converter/Regulator
The TP-VRHP-2424 is a 70W voltage converter/regulator which accepts an input of plus or minus 18VDC to 36VDC and provides a regulated output of 24VDC @ 2.9A 70W. These units are perfect for providing stable regulated 24VDC voltage from 24VDC battery banks. Input and outputs are wire terminals for wire up to 12AWG. Operates from -30 to +65 deg C.
- General Information
- Manufacturer
- Tycon Power Systems
- Manufacturer Website Address
- http://www.tyconpower.com
- Brand Name
- Tycon Power
- Product Series
- TP-VRHP
- Product Type
- DC Converter
- Technical Information
- Device Supported
- Security Device
- Wireless Base Station
- Remote Power System
- Power Description
- Output Voltage
- 24 V DC
- Maximum Output Current
- 2.90 A
- Physical Characteristics
- Height
- 133.1 mm
- Width
- 76.2 mm
- Depth
- 38.1 mm
- Weight (Approximate)
- 499 g
